Types of Construction Profiles
All square, rectangular, painted, specially shaped, oval, D profiles and construction profiles produced according to standards are delivered packaged according to your expectations and needs, both retail and wholesale.
CONSTRUCTION PROFILES category includes all distinguished brands and products compliant with TSE, DIN, BS, ISO standards, offered by YAKUP YILMAZ BORU PROFİL A.Ş. with the most suitable prices and payment options.
Profiles used in many areas, especially in the construction and manufacturing sectors, vary in cross-section (mm) and wall thickness (mm) according to dimensions and weights. Depending on the usage area, the most suitable pipe cross-section and wall thickness should be selected according to occupational health and safety, considering the strength and static values of the product.
Profiles are manufactured using advanced technology from pickled or cold-rolled steel strips in the desired steel grades.
PRODUCTION DIMENSION RANGE:
Outer Dimensions: 10x10 mm - 175x175 mm / 20x10 mm - 250x100 mm
Wall Thickness: 0.70 mm - 10.0 mm
Length: Standard length is 6 meters. Special sizes between 4 and 12 meters are available upon request.
USAGE AREAS:
Building elements (Construction Sector), Roof constructions, Automotive and automotive sub-industry, Bicycle, furniture, steel goods, and other sectors...
PRODUCTION STANDARDS:
EN 10305-5 (TS EN 10305-5), EN 10219 (TS EN 10219) CE MARKED, DIN 2395, DIN 59411, BS 6363, ASTM A 500, SI 1458, TS 5317 standards. Manufactured from DC01 (DIN EN 10130), S185, S235JRH/J0H/J2H, S275J0H/J2H, S355J0H/J2H (DIN EN 10025) steel bands using high-frequency welding (ERW).
TOLERANCES:
• Wall Thickness: ±12.5%, +10% (varies according to the net thickness order)
• Weight: ±10% per pipe, ±7.5% for 10-ton batches
• Length: ±50 mm
• Curvature: 2.5 mm/m
Operating with the principle of timely delivery according to contracts, YAKUP YILMAZ BORU PROFİL A.Ş. offers construction profiles used in various areas from construction to automotive with the most economical and maximum discounted price offers based on the current price lists.
Construction Profiles 04-11-2019 Price List - Profiles suitable for the area of use can be specially ordered. We evaluate production possibilities for desired dimensions for your large-scale orders. You can always call our call center at 444 0 245 for painted, black, galvanized options and stock status, and get the best price options.
